Shenzhen Endless Power CO., LTD

Product name : Mono solar panel / module 250w
Product No. : 201621115352
Price : Get the latest
←[Previous Product]
Online Inquiry         Email Us

  Details:
Quality and Safety

1. Rigorous quality control meets the highest international standards.

2. High-transmissivity low-iron tempered glass, strong aluminium frame.

3. Using UV-resistant silicon.

4. IS09001/14001/CE/TUV/UL



Warranties

1. 10 years limited product warranty

2. 15 years at 90% of the minimal rated power output

3. 25 years at 80% of the minimal rated power output



Technical date :

ITEM NO.: Mono 156*156 cell ,60pcs . Power range from 230Wp-260Wp
Maximum Power(W)  230 235 240 245 250  255  260
Optimum Power Voltage(Vmp)  29.4 29.5 29.7 30.1 30.3  30.5 30.7
Optimum Operatige Current(Imp)  7.83 7.97 8.08 8.14 8.25  8.37  8.48
Open Circuit Voltage(Voc)  36.7 36.8 36.9 37.1 37.3  37.5  37.7
Short Circuit Current(Isc)  8.52 8.59 8.62 8.65 8.69 8.73   8.78
Solar Cell: 156*156 mono
Number of Cell(pcs) 6*10
Brand Name of Solar Cells EP
Size of Module(mm) 1650*992*40/45/50
Cable & Connector Type Pass the TUV Certificate
Frame(Material Corners,etc.) Aluminium-alloy
Back sheet TPT
Weight Per Piece(KG) 19.5KG
FF (%) 70-76%
Junction Box Type Pass the TUV Certificate
Tolerance Wattage(e.g.+/-5%) ±3%, or 0-3%
Front Glass Thickness(mm) 3.2
Temperature Coefficients of Isc(%) +0.04
Temperature Coefficients of Voc(%) -0.38
Temperature Coefficients of Pm(%) -0.47
Temperature Coefficients of Im(%) +0.04
Temperature Coefficients of Vm(%) -0.38
Temperature Range  -40°C to +85°C
Surface Maximum Load Capacity 5400Pa
Allowable Hail Load 23m/s ,7.53g
Bypass Diode Rating(A) 12
Warranty 90% of 10 years, 80% of 25 years.
Standard Test Conditions AM1.5   1000W/ 25 +/-2°C
Packing  carton or pallet
1*20' 14 Pallets / 316pcs
1*40'STD 25 Pallets / 700pcs
