产品名称 : 太阳能系统SY0307
型号 : EP-SS-SY0307
←[上一个产品]              [下一个产品]→
询 盘         给我邮件

  产品详细:
 10w solar system with 2pcs LED light, solar system supplier, home solar system

Functions and Features:

This device is a kind of portable power supply solar system, specially made for DC power appliances and electronic products. It iswidely used inmobilephonecharging,lighting,fansand otherDCpower products.Its main features are as follow:

1: Compact chassis, LED lamps and connecting cables is very easy and convenient to use.

2:By using cables with four interfaces, we can charge several appliances simultaneously.

3:The intelligent chip control prevents the solar system from overcharge, overload, short-circuit, reverse-charging, which guarantees the whole systemtoperform effectively as well as long life duration.

4:DC 12V output can be used for DC bulb, fan and many other 12V appliances.

5:With USB cable we can charge mobile phones, electric toothbrushes, digital camera etc.

Technical Parameters:

Model

GS-SY0345

GS-SY0307

Solar Panel

8W/12V



10W/12V



Battery Capacity

4.5AH/12V

7AH/12V

MaximumChargingCurrent

1.5A

1.5A

MaximumLoadCurrent

3A

3A

RatedVoltage

DC 12V

DC 12V

USB Output

0.6A/5V

1.5A/5V

Charge Mode

ON/OFF

PWM Charging Mode

Over-loadProtection

Instant

25seconds for 120% Exceeded;8seconds for 150% Exceeded;Instant for 200%

Short-circuit Protection

Instant

Instant

Float Charge/Over Charge Voltage

14.3V

13.6V

Resumed Voltage After Discharge

10.8~11.1V

12.6V

Over-discharge Voltage

10.6~10.8V

10.8~11.1V

Self Consumption

<15mA

<15mA

Charging Circuit Voltage-drop

<1V

<250mV

Discharging Circuit Voltage-drop

<600mV

<50mV

Size

180*80*227mm

190*90*237mm

Installation Instructions:

1.Press on the“ON/OFF”button to check the working indicator light.

2.Plug the solar panel charging cable into the input port, then the chargingindicatorwill lighten if the solar panel is being put under the sun. Please check the connections of the device carefully and ensure the terminal connector is tightened, if the charging indicator does not light up. In the meanwhile, please note that the charging cable should be connected in according to the indicating diagram, so thatit canprevent the rainwater from flowing into the device.

3.Connect DC power appliances and electronic products with the device, and the system will work automatically.

10w solar system with 2pcs LED light, solar system supplier, home solar system

1. Payment term: T/T in advance (W/U for sample order)
2. Lead time: It depends on your quantity. Usually we will send sample within 5-7 working days.
3. Shipping will be made viaEMS, DHL, Fedex, UPS etc. shipment.

10w solar system with 2pcs LED light, solar system supplier, home solar system
